Products Categories
180° Hybrid
- Broadband frequency range from 0.5GHz to 26GHz
- High power handling up to 50W
- Miniaturization
- Low insertion loss
- High stability
All products can be customized according to customer needs.
Product Parameter
| Part Number | Freq Min （G） | Freq Max (G) | Insertion Loss (Typ) | Isolation (dB) | VSWR | Amplitude Unbalance | Phase Unbalance | Power Handling | In/Out Port | Inventory | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MZH8003005GA | 0.3 | 0.5 | 0.4 | 22 | 1.3 | ±0.3 | ±5 | 50 | SMA-Female | ||
| MZH800501GA | 0.5 | 1 | 0.4 | 22 | 1.4 | ±0.5 | ±10 | 50 | SMA-Female | ||
| MZH800502GA | 0.5 | 2 | 2 | 18 | 1.6 | ±1.0 | ±13 | 50 | SMA-Female | ||
| MZH800503GA | 0.5 | 3 | 2 | 18 | 1.6 | ±1.2 | ±12 | 50 | SMA-Female | ||
| MZH800504GA | 0.5 | 4 | 1.5 | 20 | 1.35 | ±1.0 | ±15 | 50 | SMA-Female | ||
| MZH80075015GA | 0.75 | 1.5 | 0.6 | 22 | 1.4 | ±0.5 | ±10 | 50 | SMA-Female | ||
| MZH80102GA | 1 | 2 | 0.6 | 22 | 1.4 | ±0.5 | ±10 | 50 | SMA-Female | ||
| MZH80204GA | 2 | 4 | 0.6 | 20 | 1.6 | ±0.5 | ±10 | 50 | SMA-Female | ||
| MZH80208GA | 2 | 8 | 1.2 | 22 | 1.4 | ±0.5 | ±6 | 30 | SMA-Female | ||
| MZH80218GA | 2 | 18 | 2.1 | 16 | 1.5 | ±0.8 | ±10 | 30 | SMA-Female | ||
| MZH80408GA | 4 | 8 | 0.6 | 18 | 1.3 | ±0.5 | ±10 | 30 | SMA-Female | ||
| MZH80408GN | 4 | 8 | 0.5 | 20 | 1.35 | ±0.3 | ±8 | 30 | N-Female | ||
| MZH804124GA | 4 | 12.4 | 1.2 | 17 | 1.6 | ±0.6 | ±10 | 30 | SMA-Female | ||
| MZH80418GA | 4 | 18 | 2 | 15 | 1.8 | ±1.2 | ±12 | 30 | SMA-Female | ||
| MZH8058062GA | 5.8 | 6.2 | 0.5 | 20 | 1.4 | ±0.3 | ±2 | 50 | SMA-Female | ||
| MZH80812GA | 8 | 12 | 1.3 | 15 | 1.5 | ±0.6 | ±8 | 30 | SMA-Female | ||
| MZH8119121GA | 11.9 | 12.1 | 1.2 | 13 | 1.6 | ±0.6 | ±2 | 50 | SMA-Female | ||
| MZH81626GA | 16 | 26 | 1.2 | 14 | 1.6 | ±0.8 | ±10 | 30 | SMA-Female | ||
| MZH8264266GA | 26.4 | 26.6 | 1.6 | 12 | 1.8 | ±1 | ±3 | 50 | SMA-Female | ||
| H8147153GA | 14.7 | 15.3 | 0.8 | 19 | 1.5 | ±0.6 | ±8 | 10 | SMA-Female | ||
| H8067077GA | 6.7 | 7.7 | 0.5 | 20 | 1.25 | ±0.3 | ±5 | 20 | SMA-Female | ||
| H800990113GA | 0.99 | 1.13 | 0.5 | 25 | 1.3 | ±0.25 | ±2 | 20W | 0.38 Microstrip Needle |
